Small-diameter PE/PPR/PE-RT/PA Single-pipe, Dual-pipe High-speed Extrusion Line

The main screw adopts BM high-efficiency type, and the output is fast and plasticized well. The wall thickness of pipe products is precisely controlled and very less waste of raw materials.
Tubular extrusion special mold, water film high-speed sizing sleeve, equipped with integrated flow control valve with scale.
Servo-controlled high-speed double-belt haul off unit, supporting high-speed chipless cutter and winder, adapt to high-speed production operation.
Dual pipe extrusion line can double the output and occupy less factory space.

Description

Product description:

Performance ＆ Advantages:

The main screw adopts BM high-effiffifficiency type, and the output is fast and plasticized well. The wall thickness of pipe products is precisely controlled and very less waste of raw materials. Tubular extrusion special mold, water fifilm high-speed sizing sleeve, equipped with integrated flflow control valve with scale. Servo-controlled high-speed double-belt haul offff unit, supporting high-speed chipless cutter and winder, adapt to high-speed production operation. Dual pipe extrusion line can double the output and occupy less factory space.

Main Technical Parameters:

Type	Pipe Spec (mm)	Extruder	Man power kw	Output (kg/h)
PE/PERT 75	Φ20～Φ75	JWS-H 60/40	110	380～420
		JWS-H 60/40	90	350～400
		JWS65/33	75	200～240
PPR 75	Φ20～Φ75	JWS-H 60/40	110	300～340
		JWS-H 60/40	90	280～320
		JWS65/33	75	160～195
PE/PERT 32	Φ16～Φ32	JWS-H 60/40	110	380～420
PE/PERT 32	Φ16～Φ32	JWS-H 60/40	90	350～400
